![TTA3150: Poly[(2-oxiranyl)-1,2-cyclohexanediol] -2-ethyl-2-(hydroxymethyl)-1,3-propanediol Ether](/uploads/image/20221009/16/tetra-special-epoxy-resin.jpg "TTA3150: Poly[(2-oxiranyl)-1,2-cyclohexanediol] -2-ethyl-2-(hydroxymethyl)-1,3-propanediol Ether")
TTA3150 poly [(2-ethylene epoxide) - 1,2-cyclohexanediol] 2-ethyl-2 - (hydroxymethyl) - 1,3-propylene glycol ether is a typical cycloaliphatic epoxy resin, which contains very little chloride ions and chloride salts. It has the characteristics of high transparency, high heat resistance, high Tg, excellent weather resistance, and excellent electrical properties (arc resistance and electric trace resistance). Its epoxy group at the end has similar reactivity with the epoxy group of polyether polyol glycidyl ether epoxy resin and can be cured with curing agents such as anhydride, phenol, amine, and cationic curing agent. It is widely used in composite materials, electrical insulation materials, electronic adhesives, powder coatings, and other fields.
| Grade | TTA3150 |
| Product name | Poly[2-oxiranyl)-1,2-cyclohexanediol]-2-ethyl-2-(hydroxymethyl)-1,3- propanediol ether |
| CAS No. | 244772-00-7 |
| Content（%） | 95.0 min |
| Epoxy equivalent (g / eq) | 170～200 |
| Chroma | 50 APHA max |
| Softening Point (℃) | 70～90 |
The curing of TTA3150 with methyl-hexahydro phthalic anhydride has excellent transparency and high heat resistance temperature; the curing with methyl-tetrahydro phthalic anhydride has slightly lower Tg and yellow color, and the curing with methylnadic anhydride has better heat resistance than that of the above two anhydrides. It shall be noted that the color after curing is brown and translucent. Special attention: TGA data show that the TTA3150 and MHHPA cured product has the highest thermal decomposition temperature, and the TTA3150 and MNA cured product has the highest Tg, but the lowest thermal decomposition temperature.
If you are interested in any Tetra Special Epoxy Resin or have any questions, please feel free to contact us.
